Glacier NU-9483 Upright Mid Capacity -86°C Ultra-low Temperature Freezer

The Glacier 9483 Upright 17.1 ft3 (483 L) Capacity Ultra Low Temperature Laboratory Freezer creates a stable, uniform, and reliable environment for the preservation of your cells while minimizing frost build up.

Download Specifications

Glacier NU-9483 Ultra-low Temperature Freezer

More Views

  • Eye level, simplified controls
  • Insulated inner doors with multi-point gasket system
  • Capacity to fit your storage needs

A Better Temperature Management System
Energy efficient cascade cooling system monitors temperature and pressures throughout high and low stage circuits. The Inner chamber is surrounded by foam-in-place polyurethane insulation from all sides. Two (2) insulated inner doors maintain interior temperature during openings. Multiple point gasket seals lock in cool temperatures while keeping out ambient air. A heated bypass coil around the inner doors reducing frost build up making it easier to access your samples. Consistent temperature uniformity throughout the chamber increases your cell viability.

Energy Efficiency
Microprocessor controls operate cooling functions creating optimal storage conditions while minimizing energy consumption.

Longer Lasting Compressors
By using the refrigeration system to help cool the oil that runs the compressors, they are able to run longer and provide greater temperature uniformity increasing reliability.

Environmentally Engineered
Glacier freezers are RoHS compliant, utilize CFC-free refrigerants and insulation eliminating ozone depletion while efficient compressors minimize energy consumption reducing our carbon footprint.

Experience Ergonomics
Eye level controls, claw-like door latches, low force door opening, and exceptionally quiet 47 dBa operation create a friendly working environment.

Watch and Alert Control System
Microprocessor controls are simple to use monitoring and controlling temperature and alarm set points. Visual and audible alarms for high and low temperature, power failure, sensor failure, battery life, fan motor life, filter check, and door ajar.

GC model includes voltage booster
Access port
Heavy-gauge steel cabinet
Heavy-duty swivel casters
Key lock
Four [4] compartments
Four [4] shelves — Three [3] adjustable

Optional Features
Cobex® temperature recorder
CO2 back-up system [NU-UB2]
Painted steel interior
Floor anchor system
Inventory system




Temperature Range -50°C to 86°C
Interior Volume
17.1 ft3 (487 L)
Area Footprint
8.37 ft2 (0.78 m2)
Exterior Dimensions (W x D x H)

35.0 x 34.3 x 78.3 in.

(890 x 870 x 1990 mm)

Interior Dimensions (W x D x H)

24.8 x 23.6 x 50.4 in.

(630 x 600 x 1280 mm)

Weight, Net 672 lbs (305 kg)
Electrical 220 V, 60 Hz 230 V, 50 Hz

2 Year Parts and Labor (US & CA)

4 Year Parts (International)

Maximum Capacity
Fiberboard Boxes 2" (50 mm) High in Racks

Boxes: 384

2ml Sample Vials (100 Cell Divididers): 32,000

Fiberboard Boxes 3" (76 mm) High in Racks

Boxes: 192

4ml Sample Vials (100 Cell Divididers): 19,200

Standard Microplate in Racks

Foil Tape Cover: 2,016

Cover Lid: 1,632

Insulated Inner Door Steel frame, high impact plastic, w/ foam-in place insulation
Inner Door Configuration Two (2)
Door Gaskets Multi-point compression gaskets
Condenser Filter Electrostatic filter, front easy access, no tools
Interior Corners Rounded for easy cleaning
Shelf Brackets Adjustable
Casters Four (4) Heavy Duty w/ leveling feet
Seismic Brackets Standard; hard connection to facility wall
Access Ports Multiple ports allow use of injection tubes, probes, leads, instrumentation
Refrigeration System
High Stage 1100 W
Low Stage 1100 W
Built-in Voltage Booster Standard on NU-9483GC
Sound Reduction Standard


Door Gaskets
