NuWindNU-C200R
General Purpose Centrifuge

Capacity 4 x 625 ml | Refrigerated | Benchtop | Rapid Rotor Exchange

The NuWind NU-C200R refrigerated model features the ability to spin either swing-out or angular rotors and a refrigeration system that enables the centrifuge bowl to maintain a consistently cool temperature. The centrifuge’s steel construction and lockable lid combine with the imbalance detection sensor to ensure safety while the Click Spin™ function allows rotors to be exchanged at the mere twist of a knob. Finally, the InSight Electronic Control Center allows easy entry of centrifugation parameters and the creation of up to 99 programs using a modern touch panel interface.

Request a Quote

A CONFIGURATION TO MEET YOUR NEEDS

The NU-C200R is offered in two electrical configurations to meet your laboratory’s needs.

Products

NU-C200R

115V, 60Hz

NU-C200R-E

230V, 50/60Hz

Quick Specs

15ml Round Bottom Tube Capacity 28 in NU-RX625 Swing-out Rotor; 12 in NU-RX400 Swing-out Rotor
50ml Conical Bottom Tube Capacity 16-20 in NU-RX625 Swing-out Rotor; 12 in NU-RX400 Swing-out Rotor; 8 in NU-RA8-50 Angle Rotor
Control System InSight
Maximum Capacity 4 x 625 ml
Maximum RCF (xg) 30,980 xg
Maximum Speed (rpm) 18,000 rpm
Number of Programs 99, Pre-cooling, Pre-warming
Temperature Accuracy °C ± 2°C
  • Features
  • Specs
  • Options & Accessories
  • Resources

CENTRIFUGATION AT THE TOUCH OF A BUTTON.

INSIGHT CONTROL CENTER

The NuWind's touch screen interface allows users to easily enter speed and time parameters for their next centrifugation run or create up to a total of 99 programs that can be reused again and again. An electronic logbook of centrifuge use and a programmable reminder to grease the equipment help ensure proactive preventive maintenance.
InSight Control Center

CHANGING ROTORS IS A SNAP...OR IN OUR CASE, A CLICK.

CLICK SPIN ROTOR EXCHANGE

You shouldn't need more than one centrifuge to spin different types of rotors and you shouldn't need to become a mechanic to trade one rotor for the other. Take advantage of the NuWind's ability to spin a wide range of both swing-out and angular rotors and exchange them by just turning a knob. Versatility is at your fingertips as you effortlessly combine the rotor, bucket, adaptors and lids that meet the needs of your specific application.
Click Spin

MAINTAIN CONSISTENT BOWL TEMPERATURE.

EASY REFRIGERATION

The refrigerated NuWind models feature a refrigeration system with pre-cooling and pre-warming programs and an adjustment range between -10C and 40C. With an ambient temperature of 20C +/-2C and while spinning an NU-RX500 rotor at a speed of 4,200 RPM, the NU-C200R can maintain a temperature of 4C.

SWING-OUT ROTOR TUBE CAPACITY AT 5100 RPM / 5470 XG

NU-RX250 SWING-OUT ROTOR

 Tube Volume 1.5/2ml 5/7ml 10ml 15ml 15ml 50ml 50ml 50ml 175-225ml 400ml
 Tube Shape Microtube Round Round Round Conical Round Conical Skirted Conical Conical
 Tubes per Rotor 120 60 48 12 28 16 12 12-16 4  4

SWING-OUT ROTOR TUBE CAPACITY AT 5100 RPM / 5350 XG

NU-RX500 SWING-OUT ROTOR

Tube Volume 1.5/2ml 5/7ml 10ml 15ml 15ml 50ml 50ml 175ml 225ml 350ml 625ml
Tube Shape Microtube Round Round Round Conical Conical Skirted Conical Conical Flat Flat
Tubes per Rotor 184 92 76 28 44 16-20 20 4 4 4 4

 Microplate Type  Standard Microplates Deep Well Blocks
 Microplates/Blocks per Rotor  16  4

MICROPLATE SWING-OUT ROTOR CAPACITY AT 5100 RPM / 4537 XG

NU-RHDW SWING-OUT ROTOR

Plate Type Plates per Rotor Speed
96-Well Microplate 8 4500 RPM / 3531 xg
96-Well "Deep Well" Plate 2 4500 RPM / 3531 xg

ANGULAR ROTOR TUBE CAPACITY AT SELECTED VELOCITIES

ASSORTED ANGULAR ROTORS

Tube Volume Tube Shape Tubes per Rotor Speed
2ml Microtubes 24 15300 RPM / 22380 xg
2ml Microtubes 30 15300 RPM / 25350 xg
2ml Microtubes 48 14000 RPM / 21720 xg
5ml Microtubes 16 13200 RPM / 21035 xg
15ml Microtubes 30 4500 RPM / 3328 xg
50ml Conical 8 12200 RPM / 16973 xg
100ml 6 10700 RPM / 13568 xg

The NuAire© Advantage

NuAire® utilizes an independent network of sales and service professionals offering our customers a vast array of knowledge and relationships. Our inside sales and service teams are the pride of the industry; some of which have been with NuAire® since the beginning in 1971. We work hard and diligently to make you happy. That is our mission, and that is why we come to work every day. Purchase a NuAire® and become part of our family.

Warranty

Backed by the Industry's Best

  • 3 Years Parts & Labor (United States and Canada)
  • Consult Local Distributor (Global)

Standard Features

  • Refrigeration System Maintains 4°C Temperature
  • 2L Swing-Out Rotor Capacity
  • Broad Range of Angle Rotors
  • Click Spin™ Rotor Exchange
  • Motorized Lid Lock
  • Imbalance Detection
  • Rotor Overspeed Prevention
  • Painted Steel Main Cabinet
  • Stainless Steel Bowl
  • InSight Electronic Control Center with touch panel
  • Power Factor Control Smooths Input Current
100ml Tube Capacity 6 in NU-RA6-100 Angle Rotor
10ml Round Bottom Tube Capacity 76 in NU-RX625 Swing-out Rotor; 48 in NU-RX400 Swing-out Rotor;
14ml Tube Capacity N/A
15ml Conical Bottom Tube Capacity 44 in NU-RX625 Swing-out Rotor; 28 in NU-RX400 Swing-out Rotor
15ml Micro Tube Capacity 30 in NU-RA30-15 Angle Rotor
15ml Round Bottom Tube Capacity 28 in NU-RX625 Swing-out Rotor; 12 in NU-RX400 Swing-out Rotor
175ml Conical Bottom Bottle Capacity 4 in NU-RX625 Swing-out Rotor; 4 in NU-RX400 Swing-out Rotor
225ml Conical Bottom Bottle Capacity 4 in NU-RX625 Swing-out Rotor; 4 in NU-RX400 Swing-out Rotor
250ml Conical Bottom Bottle Capacity N/A
290ml Flat Bottom Bottle Capacity N/A
30ml Skirted Conical Tube Capacity N/A
350ml Flat Bottom Bottle Capacity 4 in NU-RX625 Swing-out Rotor
400ml Conical Bottom Bottle Capacity 4 in NU-RX400 Swing-out Rotor;
500ml Flat Bottom Bottle Capacity N/A
50ml Round Bottom Tube Capacity 16 in NU-RX400 Swing-out Rotor;
50ml Skirted Bottom Tube Capacity 20 in NU-RX625 Swing-out Rotor; 12-16 in NU-RX400 Swing-out Rotor
50ml Conical Bottom Tube Capacity 16-20 in NU-RX625 Swing-out Rotor; 12 in NU-RX400 Swing-out Rotor; 8 in NU-RA8-50 Angle Rotor
5ml Micro Tube Capacity 16 in NU-RA16-5 Angle Rotor
5-7ml Round Bottom Tube Capacity 92 in NU-RX625 Swing-out Rotor; 60 in NU-RX400 Swing-out Rotor;
625ml Flat Bottom Bottle Capacity 4 in NU-RX625 Swing-out Rotor
750ml Flat Bottom Bottle Capacity N/A
Acceleration Slopes 9
Ambient Operating Temperature (°C) 20⁰C ± 2⁰C
Braking Slopes 10
Construction Painted Steel Main Cabinet, and Stainless Steel Bowl
Control System InSight
Deep Well Blocks Capacity 4 in NU-RX625 Swing-out Rotor; 2 in NU-RHDW Rotor;
Electrical Configuration 115V60Hz, 230V5060Hz
Environment Altitude 6562 Feet (2000 meters) above sea level
Environment Humidity Maximum relative humidity 80% for temperatures up to 31⁰C decreasing linearly to 50% relative humidity at 40⁰C
Environment Temperature Range 60⁰F - 85⁰F (15⁰C - 30⁰C)
Exterior Depth Inches (mm) 23 (582)
Exterior Height Inches (mm) 12.75 (322)
Exterior Width Inches (mm) 26.5 (675)
Footprint Depth inches (mm) 23" (582mm)
Footprint Width inches (mm) 26.7" (675mm)
For indoor use only True
Heat Rejected (BTU/Hour) 6824
Imbalance Detection Sensor True
Maximum Capacity 4 x 625 ml
Maximum RCF (xg) 30,980 xg
Maximum Speed (rpm) 18,000 rpm
Standard Microplates Capacity 16 in NU-RX625 Swing-out Rotor; 8 in NU-RHDW Rotor;
1.5-2.0ml Micro Tube Capacity 184 in NU-RX625 Swing-out Rotor; 120 in NU-RX400 Swing-out Rotor; 48 in NU-RA48-2 Angle Rotor; 30 in NU-RA30-2 Angle Rotor; 24 in NU-RA24-2 Angle Rotor;
Motorized Lid Lock True
Net Weight lbs (kg) 242 (110)
Number of Programs 99, Pre-cooling, Pre-warming
Optimal Refrigeration Settings +4°C temperature with NU-RX500 rotor can be maintained at 4,200RPM at an ambient temperature of 20⁰C ± 2⁰C
Power Consumption 1600
Power Cord Length Foot (Meter) Inquire
Refrigerant R404A
Refrigerant Charge 0.35 kg
Rotor Speed Control True
Shipping Dimensions 19.8" (500mm) x 31.7" (800mm) x 31.7" (800mm)
Shipping Weight lbs (kg) 277 (216)
Sound Level ≤ 55 dB(A)
Speed Control Precision RPM ± 10 rpm
Style Bench Top
Temperature Accuracy °C ± 2°C
Temperature Control Range -10°C to 40°C

Electrical

NU-C200R NU-C200R-E
Electrical Configuration 115V60Hz 230V5060Hz
Nominal Intensity 17 A 8.5 A
